TR3060-0010
TwinCAT 3 training: TwinSAFE Basics
This Beckhoff course is designed to introduce TwinSAFE hardware and software products.
Overview
This Beckhoff course is designed to introduce TwinSAFE hardware and software products, and bring the student to a level of familiarity with the technology. An overview of the product features and functionality, as well as the basic use of the software will be discussed.
Requirements
A PC with a Windows operating system. TwinSAFE hardware PLC and supporting hardware, fieldbus required for full interactivity.
Objectives
General TwinSAFE hardware functionality,
Options for TwinSAFE system architecture,
TwinSAFE programming basics,
Project navigation,
Alias assignments,
Function block implementation,
Program validation, deployment,
Basic diagnostics
Course Curriculum
TwinSAFE Hardware
Available in
days
days
after you enroll
- Introduction (0:15)
- What is TwinSAFE? (0:41)
- TwinSAFE Architecture: On the Machine (0:39)
- TwinSAFE Architecture: Machine to Machine (0:24)
- TwinSAFE Communication Protocol (0:30)
- Calculating Reaction Time (0:28)
- Terminal Part Numbers: Overview (1:21)
- Terminal Part Numbers: Examples (1:30)
- TwinSAFE Safety PLC Terminals (0:29)
- EL6910 Specification (0:54)
- All New TwinSAFE Components are Logic-Capable! (0:25)
- New Design Possibilites (1:19)
- TwinSAFE Digital Input Devices (0:26)
- Compact Controllers - EL1918 (0:52)
- Test Pulses (0:38)
- EL1918 Diagnostics LEDs (0:23)
- TwinSAFE Digital Output Devices (0:17)
- EL2912 Overview (0:34)
- EL2912 LEDs (0:21)
- Combination Terminals (1:07)
- Standalone Modules (1:09)
- Terminal Placement Recommendations: Cabinet Mounting (1:02)
- Terminal Placement Recommendations: Grouping (0:42)
- FSoE Addressing (0:48)
- Safe Motion (3:07)
- Application Guide (0:45)
TwinSAFE Project Basics - Part 1
Available in
days
days
after you enroll
- Introduction (0:11)
- Table of Contents (0:27)
- Before We Start (0:36)
- Creating a TwinSAFE Project (0:33)
- TwinCAT 3 Safety Wizard (0:38)
- TwinSAFE Project Basics (0:08)
- Project Layout (0:22)
- Target System Configuration (0:17)
- Choose Target System (0:15)
- Select Physical Device (0:15)
- Set Safe Address (0:31)
- Save Target System Configuration (0:38)
- TwinSAFE Groups (0:31)
- Alias Devices (0:27)
- Import Alias Devices (0:27)
- Hardware Alias Device Settings (0:31)
- Safety Parameters Settings (0:15)
- Add Alias Device (0:42)
- Standard Alias Devices (0:39)
- Linking Standard Alias Devices to PLC (0:24)
- Safety Logic (0:34)
- Creating Safety Logic (0:21)
- Linking Safety Logic (0:24)
- Function Block Execution Order (0:34)
- Function Block Configuration Parameters (0:24)
- Function Block Input and Output Port Configuration (0:23)
- Assign Variable To Port (0:24)
- Variable Mapping Tab (0:30)
- Variable Assignments and Usages (0:14)
- Global Variables (0:33)
- Creating Global Variable Lists (0:24)
- Adding Global Variables (0:14)
- Safety Project Download (0:06)
- Safety Project Download Checklist (0:45)
- Target System Serial Number (0:18)
- Verify Complete Safety Project (0:32)
- Downloading the Safety Project (0:15)
- Safety Project Download Login Page (0:31)
- Select Project Data (0:20)
- Safety Project Download Results (0:12)
- Safety Project Download Verification (0:31)
- Safety Project Download Activation (0:10)
- Safety Project Download Successful (0:41)
- Activate Configuration (0:15)
- Safety System Online View (0:12)
- TwinSAFE Online View (0:19)
- TwinSAFE Online View Status (0:18)
- Common Safety Group Statuses (0:43)
- Error Reset Procedure (0:25)
- Error Acknowledgement (0:19)
- Function Block Status Indicator (0:12)
- Common Status Indicator Symbols (0:40)
- Error Reset Procedure (0:18)
TwinSAFE Project Basics - Part 1 - Live Walkthough
Available in
days
days
after you enroll
- Introduction (0:14)
- Preparing the Project (1:23)
- Add Safety Project (1:32)
- Configure Target System (2:53)
- Configure Alias Devices (2:57)
- Create Safety Logic (1:39)
- Create Safety Variables - Configure Logic (6:13)
- Linking Alias Devices to Variables (4:22)
- Linking PLC Variables (4:15)
- Verify Safety Application (1:30)
- Download Safety Application (3:30)
- Activate Configuration (0:32)
- Show Online View (0:13)
TwinSAFE Project Basics - Part 2
Available in
days
days
after you enroll
- Introduction (0:10)
- Overview (0:16)
- EL6900 vs EL6910 (0:28)
- EK1960 (0:22)
- TwinSAFE Project Diagnostics (0:02)
- Show Online Data (0:16)
- Safety Group Status Bar (0:09)
- Function Block Status Indicator (0:10)
- Locating Diagnostic Information (0:23)
- Group Ports RunStop and ErrAck (0:44)
- Group Ports Common Errors (0:48)
- Safety Project Online View (0:38)
- Group Ports Additional Newer Diagnostics (0:09)
- Safety Project Online View Closeup (0:37)
- State and Diagnostic Mapping (0:29)
- Group Mapping (0:18)
- Group State (0:04)
- Group Diag (0:23)
- Connection Mapping (0:44)
- Connection State (0:28)
- Function Block Mapping (0:23)
- Diagnostic History (0:11)
- Diagnostic History Tab (0:21)
- Diagnostic History Advanced Settings (0:14)
- User Administration (0:05)
- User Administration Basics (0:29)
- Adding New Users (0:24)
- User Rights (0:07)
- User Administration Version History (0:16)
- TwinSAFE SC Introduction (0:06)
- TwinSAFE SC (0:38)
- TwinSAFE SC Setup Requirements (0:02)
- Enable TwinSAFE SC Communication (0:13)
- Select FSoE Address (0:24)
- Select CRC Settings (0:30)
- TwinSAFE SC Process Data Options (0:13)
- TwinSAFE SC Supported Data Types (0:16)
- Additional Analog Function Blocks (0:11)
- TwinSAFE SC Application Examples (0:06)
- Application Examples (0:26)
- TwinSAFE Customization (0:09)
- Customization Options (0:14)
- How to Customize (0:24)
- Customization Dialog Box (0:14)
- Persistent Analog Inputs (0:08)
- Saving Analog Inputs (0:26)
